| General |
| Inputs |
5 Single-Ended, 5 Balanced, 1 Relay Trigger (3.5 mm Mono Jack) |
| Outputs |
5 Pairs Speaker Binding Posts, 1 Relay Trigger (3.5 mm Mono Jack) |
| THD+N (225 W into 8 O) |
0.0007% at 1 kHz, 0.008% at 20 kHz |
| IMD |
0.00019% (CCIF, 325 W into 8 O) |
| POWER BANDWIDTH |
10 Hz to 150 kHz
(+0 -3 dB, 325 W into 8 O) |
| FREQUENCY RESPONSE |
20 Hz to 20 kHz (+0 -0.15 dB),
5 Hz to 100 kHz (+0 -2 dB) |
| INPUT SENSITIVITY (RCA and XLR 0 dB inputs) |
1 Vrms in for 28.3 Vrms out
(100 W into 8 O) |
| INPUT IMPEDANCE |
18 kO (RCA), 22 kO (XLR) |
| DAMPING FACTOR |
>600 at 20 Hz, 400 at 1 kHz (ref. 8 O) |
| S/N RATIO |
125 dB, A-weighted (ref. 325 W) |
| CROSSTALK (between any two channels) |
-140 dB (20 Hz), -80 dB (20 kHz) |
| VOLTAGE GAIN |
29 dB |
| SLEW RATE |
40 V/µs |
| SWITCHES |
| Front Panel |
Power (On/Off) |
| Rear Panel |
On/Off Modes (Trigger, Manual, Auto), Inputs (RCA, XLR, XLR -6dB) |
POWER OUTPUT
(Per channel, continuous RMS, 20 Hz to 20 kHz, <0.1% THD, one or all channels driven.)
|
| Impedance |
8O |
4O |
2O |
| # of Channels Driven |
1 |
All |
1 |
All |
1 |
All |
|
325 W |
325 W |
500 W |
500 W |
675 W |
675 W |
Statement P2 and P5 amplifiers are stable into any impedance down to a short circuit at full output.
|
| POWER REQUIREMENTS |
| SUPPLY VOLTAGE |
105 to 130 V, 60 Hz |
| POWER CONSUMPTION |
2 x 1800 W |
| DIMENSIONS |
| Height |
9-3/8 inches (23.8 cm) including feet |
| Width |
Faceplate 19-1/4 inches (49 cm)
Chassis 17-1/4 inches (43.8 cm) |
| Depth |
22-1/2 inches (57.2 cm) including handles |
| Weight (unpacked) |
130 lb (59 kg) |
